KiCad 9 API
KiCad Version 9 introduced a new socket-based API for controlling PCB design elements. It is designed to be more stable and better supported than the legacy Python based API, with schematic control planned for future releases. For an MCP server, this is the perfect interface.
The Goal
KiCad has a rich plugin ecosystem, but I frequently encounter repetitive tasks that are too small to justify writing a dedicated script, but too tedious to do manually. I wanted to see if I could use a Claude prompt to handle those quick tasks like strange layout patterns or board audits that are too small to automate with a dedicated script.
The Test:
I created a board with 64 LEDs and asked Claude to arrange them in two concentric circles. The agent had to:
1. Analyze the board: Retrieve the Edge.Cuts geometry and identify all LED footprints.
2. Calculate the geometry: Determine the polar coordinates for two rings.
3. Execute the layout: Batch move the footprints into their final positions.
Note: While KiCad 9 can do this via the GUI Array Tool, the goal was to see how it handle a simple test.
The Result
The result was correct, but the execution took about two minutes, which is a bit slower than I’d like. The bottleneck seems to be the planning phase where Claude interprets the layout.
I found that for complex tasks, it’s better to ask Claude to write a Python script for the API rather than performing individual actions. It seems tobe more reliable at executing complex math within a script than trying to "think" through coordinates behind the scenes.
Overall, while the Oscilloscope MCP feels it will be more useful in my workflow, I could see KiCad integration helpful for one-off tasks where you're too lazy to make a script.
The MCP Server
Here are the commands the tool supports:
| Tool | Description |
|---|---|
ping |
Check KiCad connectivity |
get_version |
Get KiCad version string |
get_board_info |
Summary of footprints, tracks, vias, nets, and zones |
get_footprints |
List footprints with position, layer, and value |
get_nets |
List all nets by name and code |
get_tracks |
List all copper track segments |
get_vias |
List all vias |
get_zones |
List all copper zones |
get_board_outline |
Return the Edge.Cuts geometry |
get_component_connections |
Show net connectivity and shared neighbors |
move_footprint |
Move a footprint to an absolute position |
rotate_footprint |
Set absolute rotation in degrees |
batch_move_footprints |
Move multiple footprints in one undo step |
create_track |
Add a copper track segment to a named net |
remove_items_by_id |
Remove board items by ID |
refill_zones |
Refill all copper zones |
save_board |
Save the board to disk |
A Note on Token Usage
Commands like get_component_connections can use a lot of tokens on even simple boards. To keep things efficient, use the reference_filter to narrow your scope and rely on get_board_info for high level summaries.
